Concorde V6-3.5L VIN F (1994)
Ignition Lock: Adjustments
Floor Shift Interlock Adjustment
Fig. 6 Interlock Adjustment Lever Nut
Fig. 7 Interlock Cable At Floor Shifter
1.
Remove shifter handle and console bezel.
2.
Loosen adjustment nut on interlock lever.
3.
Place ignition in Run position.
4.
Remove interlock cable from shifter housing and slide cable out of groove in interlock lever.
5.
Inspect cable as follows:
a. With lock cylinder in Off position and ignition key removed, cable core wire should not move when pulled.
b. With lock cylinder in Run position, cable core wire should slide freely when pulled. Also, cable should return to the bottomed out position
when released.
6.
Place shifter in Park position.
7.
Slide interlock cable core wire into groove on adjustment lever. Ensure cable end seats into groove.
8.
Slip cable into housing until it snaps into place.
9.
Keeping shifter in Park position, place lock cylinder in Off position and remove ignition key.
10.
Loosen adjustment nut and allow cable to adjust itself to correct position then tighten adjustment nut.
11.
Inspect interlock cable adjustment as follows:
a. With ignition lock in Off position, shifter should be locked in the Park position.
b. Without starting engine, place ignition switch in the Run position. Move shifter to the reverse position. Ignition key should not be able to be
removed from lock cylinder.
c. Place shifter into Park position and turn ignition key to Off position. Ignition key should be able to be removed from the lock cylinder.
d. If shifter and ignition key does not perform as described in steps a through c, repeat adjustment procedure.
12.
Install shifter console bezel and shifter handle.
