Concorde V6-3.5L VIN V (2003)
![background image](/chrysler/concorde/v6-3.5l_vin_v/Page-1602001.png)
Hydraulic System Junction Block: Service and Repair
JUNCTION BLOCK
REMOVAL
1. Disconnect and isolate the negative battery connection at the right front strut tower.
Brake Pedal Holding Tool
2. Using a brake pedal holding tool such as shown, depress brake pedal past its first 1 inch of travel and secure in this position. This will isolate the
master cylinder reservoir from the brake hydraulic system, not allowing the brake fluid to drain out of the reservoir.
3. Remove screw fastening the speed control servo to the upper radiator closure panel.
4. Remove screw fastening the washer filler tube to the upper radiator closure panel.
