Crossfire SRT-6 V6-3.2L SC VIN N (2005)
Power Seat Motor: Service and Repair
Horizontal and Front Riser Motor
Horizontal Motor
REMOVAL
1. Remove the front seat.
2. Disconnect the horizontal motor harness connector (1).
3. Remove the horizontal motor attachment screws (1).
4. Remove the horizontal motor.
INSTALLATION
