Crossfire SRT-6 V6-3.2L SC VIN N (2005)
Parking Brake Lever: Service and Repair
LEVER
REMOVAL
1. Remove the parking brake equalizer return spring (4).
2. Loosen the parking brake equalizer tensioning bolt (3).
3. Remove the bolt at the parking brake equalizer (1) attaching the front parking brake cable to the equalizer.
4. Remove the shifter bezel (1).
5. Pull the rubber handle (1) off of the parking brake lever.
Note: The rubber handle can only be removed from the parking brake lever with great force (suction). If necessary cut open with a suitable tool.
6. Remove the center console (2).
7. Disconnect the parking brake switch harness connector.
