Crossfire SRT-6 V6-3.2L SC VIN N (2005)
Fuse Block: Service and Repair
Engine Fuse Block
REMOVAL
1. Disconnect and isolate the negative battery cable.
2. Open the lid (1) of the engine fuse block.
3. Remove the nuts and the electrical leads to the engine fuse block.
4. Close the lid to the engine fuse block.
5. Push the tab at the front of the engine fuse block box and remove it from the vehicle.
INSTALLATION
