Crossfire SRT-6 V6-3.2L SC VIN N (2005)
Windshield Washer Reservoir: Service and Repair
REMOVAL
1. Disconnect the negative battery cable.
2. Remove the rear half of the right front inner fender liner.
3. Disconnect the washer fluid level switch (4) harness connector.
4. Disconnect the washer pump motor harness connector (3).
5. Remove the washer pump motor supply hose from the washer pump motor (3).
6. Remove the washer fluid filler tube (1) from the washer reservoir.
7. Remove the washer reservoir attachment bolt (2).
8. Carefully pull the washer reservoir forward to release the rubber mounting grommets.
9. Remove the washer reservoir from behind the right front wheel.
INSTALLATION
