Diagram Information and Instructions|Page 4762 > < Diagram Information and Instructions

Laser L4-135 2.2L SOHC Turbo VIN E FI (1984)

Page 1
background image

Brake Switch (Cruise Control): Electrical Diagrams

Fig. 32  Hazard & Turn Flasher System & Stop Switch Wiring Circuit (Part 1 of 2). 1984

Diagram Information and Instructions|Page 4762 > < Diagram Information and Instructions
