Chrysler Workshop Service and Repair Manuals > Lebaron Coupe L4-135 2.2L SOHC Turbo VIN E FI (1987) > Relays and Modules | Relays and Modules - Instrument Panel | Active Check Module | Component Information | Diagrams | Diagram Information and Instructions | Page 77

Electronic Voice Alert Module <--> [Audible Warning Device Control Module] > < Diagram Information and Instructions|Page 76

Page 3

background image

Fig. 65 Visual Message Center Wiring Circuit

Relays and Modules
Relays and Modules - Instrument Panel / Active Check Module / Diagrams / Diagram Information and Instructions
Page 77

Electronic Voice Alert Module <--> [Audible Warning Device Control Module] > < Diagram Information and Instructions|Page 76
