LHS V6-3.5L VIN F (1995)
Window Frame: Technical Service Bulletins
Door Glass Lift Plate - Service/Replacement
NO: 23-11-95
GROUP: Body
DATE: Mar. 10, 1995
SUBJECT:
Door Glass Lift Plate Service
MODELS:
1993-1995 (LH) Concorde/Intrepid/Vision/LHS/New Yorker
DISCUSSION:
Door glass lift plates are now serviced separately from the glass. Anytime the door glass is intact and the lift plate is worn or damaged, perform the
following repair procedure.
PARTS REQUIRED:
2
4756744
Lift Plate, Door Glass
AR
NPN
Urethane Windshield Sealer (3M P/N 08609 or Equivalent)
REPAIR PROCEDURE:
This bulletin involves replacing door glass lift plates.
1.
Remove door trim panel and upper trim retainer channel.
2.
Connect power window switch or install crank and lower to 50 mm (2 in.) from bottom of travel.
3.
Loosen screws holding regulator roller channel to glass.
4.
Slide roller channel rearward to allow screw heads to pass through key slots in channel.
5.
Separate glass from roller channel.
6.
Raise glass upward and out of opening at top of door.
7.
Mark location of lift plates on glass (both lift plates should be serviced even if only one is worn or broken).
8.
Heat lift plate with propane torch to soften urethane and pry lift plate from glass by inserting flat screw driver between edge of glass and plate.
9.
Clean any remaining urethane from glass surface.
10.
Apply urethane windshield sealer to channel in new lift plate.
11.
Push and/or tap lift plate onto glass in the previously marked position.
