Pacifica V6-3.8L VIN L (2005)
Console: Service and Repair
Floor Console Base Assembly
FLOOR CONSOLE BASE ASSEMBLY
REMOVAL
1. Remove front and rear floor consoles.
2. Remove shift mechanism.
Fig. 15
3. Remove nine attaching nuts and washers to weld studs (Fig. 15).
4. Remove two screws attaching L-brackets to instrument panel.
5. Disconnect wire connectors that are still connected.
6. Raise floor console base assembly to allow wire harness exit through console base.
7. Remove floor console base assembly from vehicle.
INSTALLATION
1. Place floor console base assembly into position (Fig. 15).
2. Install wire harnesses through console base into position.
3. Connect wire connectors.
4. Install two screws attaching L-brackets to instrument panel.
5. Install nine attaching nuts and washers to weld studs.
6. Install shift mechanism.
7. Install front and rear floor consoles.
