Pacifica V6-3.8L VIN L (2005)
Utility Storage Compartment: Service and Repair
REAR FLOOR STOWAGE BIN
REMOVAL
1. Open liftgate.
Fig. 26
2. Open rear floor storage bin lid (Fig. 26).
3. Remove attaching screws 4.in the bottom of bin.
4. Remove floor storage bin from vehicle.
INSTALLATION
1. Place floor storage bin into position (Fig. 26).
2. Install attaching screws (4) in the bottom of bin.
3. Close rear floor storage bin lid.
4. Close liftgate.
