Page 3
background image

10) Disconnect the 47-way connector from the antilock brake module (ABM) by depressing the tabs on each side of the connector cover (Fig. 22),

then pulling outward and upward on the lower half of the cover until it locks into position pointing straight outward. The connector can then be
pulled straight outward off the ABM (Fig. 23).
