Pacifica V6-3.8L VIN L (2005)
Timing Cover: Service and Repair
TIMING CHAIN COVER
REMOVAL
1) Perform the fuel pressure relief procedure.
2) Disconnect negative cable from battery.
3) Evacuate air conditioning.
4) Drain cooling system.
5) Remove the air cleaner assembly.
6) Loosen the water pump pulley bolts (Fig. 175).
7) Remove the accessory drive belt and belt tensioner.
8) Remove power steering pump fasteners and set pump aside (Fig. 175).
9) Remove the generator.
10) Disconnect the air conditioning compressor clutch electrical connector and suction discharge hoses (Fig. 175).
11) Remove the oil level indicator tube.
12) Raise vehicle on hoist.
13) Drain engine oil.
14) Remove right wheel and inner splash shield.
15) Remove oil pan.
