Pacifica V6-3.8L VIN L (2005)
Drive Belt: Customer Interest
Engine - Accessory Drive Belt Shield Missing
NUMBER: 07-001-05
GROUP: Body
DATE: May 14, 2005
THIS BULLETIN IS BEING PROVIDED IN ADVANCE. DO NOT ORDER PARTS OR PERFORM ANY ACTIONS RELATED TO THIS
BULLETIN UNTIL MAY 20, 2005.
SUBJECT:
Accessory Drive Splash Shield Damaged and/or Missing
OVERVIEW:
This bulletin involves replacing the existing splash shield with an updated shield.
MODELS:
2004 - 2005
(CS)
Pacifica
NOTE:
This bulletin applies to vehicles built on or before May 16, 2005 (MDH 0516XX).
SYMPTOM/CONDITION:
The accessory drive belt shield is damaged or missing.
DIAGNOSIS:
If the Symptom/Condition is present, perform the Repair Procedure.
PARTS REQUIRED:
SPECIAL TOOLS/EQUIPMENT REQUIRED:
REPAIR PROCEDURE:
1.
Remove the existing accessory drive belt shield if present.
2.
Install the new shield, p/n 05054374AA, and install new push pins in the three existing holes that line up with the new shield.
3.
If the vehicle was built on or after February 1, 2005 (MDH 0201XXX), proceed to Step # 8. If the vehicle was built on or before January 31, 2005
(MDH 0131XX), proceed to the next step.
