Pacifica V6-3.8L VIN L (2005)

Page 2
background image

Short Runner Valve Solenoid Removed

5. Remove short runner valve.

INSTALLATION

Short Runner Valve Solenoid Removed

1. Install short runner valve.
2. Install the 4 bolts and tighten.
