Pacifica V6-3.8L VIN L (2005)
Knee Blocker Airbag - Remove/Install
4. Remove four knee blocker airbag retaining bolts from airbag.
5. Pull down knee blocker airbag and disconnect the one electrical connector.
6. Remove knee blocker airbag from vehicle.
INSTALLATION
1. Place the knee blocker airbag into position in the instrument panel opening.
2. Connect the one electrical connector.
3. Install the four knee blocker airbag retaining bolts into the airbag.
4. Position the steering column opening cover over retaining slots and firmly snap into place. Install the two retaining screws.
WARNING: DO NOT CONNECT THE BATTERY NEGATIVE CABLE. FIRST. FAILURE TO DO SO COULD RESULT IN
OCCUPANT PERSONAL INJURY OR DEATH.
5. Verify vehicle and system operation.
6. Close hood.
