Pacifica V6-3.8L VIN L (2005)
![background image](/chrysler/pacifica/v6-3.8l_vin_l/Page-392001.png)
Washer Fluid Level Switch: Service and Repair
REMOVAL
1. Open hood, disconnect and isolate the battery negative cable.
2. Hoist vehicle.
3. Turn the front of the left wheel inward.
4. Loosen inner splash shield enough to gain access to the washer reservoir.
5. Disconnect the electrical connector to the washer fluid level switch.
Washer Pump Motor And Washer Fluid Level Switch - Remove/Install
6. Pull the washer fluid level switch from the reservoir.
NOTE: Make sure to use a new grommet when installing a new switch, or even reinstalling the old switch back into the reservoir.
INSTALLATION
NOTE: Make sure to use a new grommet when installing a new switch, or even reinstalling the old switch back into the reservoir.
1. With grommet installed, position the washer fluid level switch in grommet and firmly snap into place .
2. Connect the washer fluid level switch electrical connector.
3. Install inner splash shield.
4. Lower vehicle from hoist.
5. Connect the battery negative cable.
