Radio, Stereo, and Compact Disc|Diagrams|Page 7305 > < Radio/Stereo Noise Filter|Description and Operation|Page 7301

PT Cruiser L4-2.4L Turbo VIN 8 (2005)

Page 1
background image

Speaker: Diagrams

Left Front Door Speaker

Left Instrument Panel Speaker

Left Rear Speaker (PT27 Base)

Left Rear Speaker C1 (PT27 Premium)

Left Rear Speaker C1 (PT27 Premium)
