PT Cruiser L4-2.4L Turbo VIN 8 (2005)
Refer to the Windshield Removal procedure for description of tools and adhesive systems that are recommended for use in this procedure.
1. Install the Liftgate window molding (2) on glass (1).
2. Apply a 10 mm (0.4 in.) bead of urethane around the perimeter of the glass (1).
3. Place liftgate window glass (1) into position.
4. Install the glass in the same manner described in the Windshield Install.
5. Connect rear window defogger wiring (2).
6. After urethane has cured, water test rear window to verify repair. Verify rear window defogger operation.
7. Install and connect the CHMSL lamp.
8. Install liftgate trim panels.
