PT Cruiser L4-2.4L Turbo VIN 8 (2005)
8.
Disconnect the left front brake tube (2nd inboard position) from the ABS hydraulic control unit (HCU) (Figure 1).
9.
Raise the vehicle on an appropriate hoist.
10.
Disconnect the left front wheel speed sensor wiring clips from the brake tube.
11.
Disconnect the left front brake tube from the left front brake hose (Figure 2).
12.
Remove the brake tube from the vehicle and discard it.
13.
Install the new brake tube into the vehicle and loosely connect it to the brake hose.
14.
Lower the vehicle.
15.
Loosely connect the new brake tube to the ABS HCU.
