PT Cruiser L4-2.4L VIN B (2001)
Fig.6 Battery Connection
8. Loosen the lower pivot bolt (Fig. 5).
9. Loosen the accessory drive belt t-bolt.
10. Unplug field circuit from generator (Fig. 5).
11. Remove the B+ terminal nut and wire.
12. Remove the generator belt, refer to the Cooling for more information.
13. Remove the axle retaining nut.
14. Remove the lower control arm from steering knuckle.
15. Remove axle shaft. Put a container under the transmission to catch the transmission fluid from the transmission.
16. Remove the generator lower mounting bolt and nut from the upper adjustment bracket.
Fig.7 Generator Removal
17. Remove generator out the bottom (Fig. 7).
INSTALLATION
1. Install generator (Fig. 7)and loose assemble the bolt and nut (Fig. 5).
2. Install the generator belt, refer to the Cooling for more information.
3. Install axle shaft, refer to the Axle
4. Install lower control arm to steering knuckle, refer to the Suspension.
5. Install the lower ball joint nut and tighten
