PT Cruiser L4-2.4L VIN B (2001)
Clutch: Specifications
Clutch Pack Clearances
Low/Rev Clutch (Select Reaction Plate)
0.035 - 0.058 in
Two/Four Clutch (No Selection)
0.030 - 0.104 in
Reverse Clutch (Select Snap Ring)
0.035 - 0.054 in
Overdrive Clutch (No Selection)
0.042 - 0.128 in
Underdrive Clutch (Select Reaction Plate) 0.037 - 0.059 in
Input Shaft End Play
0.005 - 0.025 in
L/R Clutch Retainer
45 in.lb
