<<A>> STEERING LOCK CYLINDER REMOVAL

1. Insert the key in the steering lock cylinder and turn it to the ACC position.
2. Using a small Phillips head screwdriver, pull the steering lock cylinder toward you.

INSTALLATION SERVICE POINT

>>A<< IMMOBILIZER-ECU INSTALLATION

If the immobilizer-ECU is replaced, peel oft the immobilizer serial number sticker from shown position. Then attach a new immobilizer-ECU
identification sticker.
