CAUTION:  The steering lock bracket and bolts must be replaced with new ones when the steering lock is installed.

1. When installing the steering lock cylinder and steering lock bracket to the column tube, temporarily install the steering lock in alignment with

the column boss.

2. After checking that the lock works properly, tighten the special bolts until the head twists off.
