Sebring Coupe V6-3.0L VIN H (2005)
<3.0L ENGINE>
DISASSEMBLY SERVICE POINT
<<A>> PISTON ASSEMBLY REMOVAL
1. Cover with a shop towel to prevent the piston from popping out.
CAUTION: Apply compressed air slowly to prevent brake fluid from splashing.
2. Apply the compressed air into the tube mounting hole to remove the piston assembly.
ASSEMBLY SERVICE POINT
