Cruise Control Switch: Diagrams

Component ID:

296

Component :

SWITCH-SPEED CONTROL

Connector:

Name :

SWITCH-SPEED CONTROL

Color :

BLACK

# of pins :

3

Pin

Circuit

Description

  1

V38 22VT/OR

S/C SIGNAL 2

  2

V937 22VT/BR

S/C SWITCH GROUND

  3

V37 22VT

S/C SIGNAL 1
