Voyager L4-2.4L VIN B (2001)
Piston Ring: Specifications
Top Compression Ring Ring Gap
0.0098-0.020 in
- Wear Limit
0.031 in
Ring Side Clearance 0.0011-0.0031 in
- Wear Limit
0.004 in
Ring Width
0.057-0.059 in
2nd Compression Ring
Ring Gap
0.009-0.018 in
- Wear Limit
0.031 in
Ring Side Clearance 0.0011-0.0031 in
- Wear Limit
0.004 in
Ring Width
0.057-0.059 in
Oil Control Steel Rails
Ring Gap
0.0098-0.025 in
Wear Limit
0.039 in
Oil Ring Pack
Ring Side Clearance 0.0004-0.0070 in
Ring Width
0.107-0.1133 in
