Lanos S Sedan L4-1.6L DOHC D-TEC MFI (2001)
Power Steering Pump: Service and Repair
SOHC Pump Drive Pulley
SOHC PUMP DRIVE PULLEY
Removal Procedure
1. Remove the air cleaner housing by removing the housing bolts and loosening the clamp.
2. Loosen the steering pump pulley bolts.
3. Remove the pump drive belt from the pulley by loosening the alternator adjusting bolt and pulling it forward.
4. Remove the steering pump pulley bolts that connect the pulley to the pump.
5. Remove the pulley from the pump.
Installation Procedure
1. Replace the pump on the engine if the pump was previously removed.
