Leganza SE L4-2.2L DOHC D-TEC MFI (2001)
Condenser HVAC: Service and Repair
Removal Procedure
1. Disconnect the negative battery cable.
2. Discharge and recover the refrigerant. Refer to "Discharging, Adding Oil, Evacuating, and Charging Procedures for A/C System".
3. Remove the radiator. Refer to Engine Cooling.
4. Remove the discharge hose connecting block-to-condenser retaining nut.
5. Remove the hose from the condenser.
6. Remove the high-pressure pipe-to-receiver-dryer connecting block nut.
7. Remove the pipe from the receiver-dryer.
