Aries L4-135 2.2L VIN C 2-bbl (1985)
FIGURE 5 - WIRE ROUTING
3.
Route wiring and install the straps as detailed in Figure 5.
4.
Disconnect one side of the A/C cycling clutch switch. Connect female end of A/C ambient temperature switch to A/C cycling clutch switch.
Connect male end of A/C ambient temperature switch to connector previously removed from A/C cycling clutch switch.
5.
Check systerm for proper operation.
Aries, Caravelle, Lebaron, New Yorker, Reliant and 600
1.
Switch location access - location can be accessed from underside of fascia. Remove left side horn bracket.
