FIGURE 5 - WIRE ROUTING

3.

Route wiring and install tie straps as detailed in Figure 5.

4.

Disconnect one side of the A/C cycling clutch switch. Connect female end of A/C ambient temperature switch to A/C cycling clutch switch.
Connect male end of A/C ambient temperature switch to connector previously removed from A/C cycling clutch switch.

5.

Check system for proper operation.

POLICY:

Reimbursable within the provisions of the warranty

TIME ALLOWANCE:
Labor Operation No.

24-35-50-92............................

0.4 Hrs.

FAILURE CODE:

56 - Internal Defect
