Caravan FWD V6-3.3L VIN 3 Flex Fuel (2001)
Wiper Motor: Technical Service Bulletins
Rear Wiper - Inoperative/Intermittently Inoperative
NUMBER: 08-003-01 REV. A
GROUP: Electrical
DATE: Mar. 9, 2001
THIS BULLETIN SUPERSEDES TECHNICAL SERVICE BULLETIN 08-003-01, DATED FEBRUARY 16, 2001, WHICH SHOULD BE
REMOVED FROM YOUR FILES. THE REVISION IS HIGHLIGHTED WITH **ASTERISKS** AND INCLUDES A CHANGE IN THE WIPER
MOTOR BUILD DATE CODE.
SUBJECT:
Rear Wiper Inoperative Or Intermittently Inoperative
OVERVIEW:
This bulletin involves reprogramming or replacing the Body Control Module (BCM) and on some vehicles, replacing the rear wiper motor.
MODELS:
2001 (RS) Town & Country/Voyager/Caravan
2001 (RG) Chrysler Voyager (International Markets)
SYMPTOM/CONDITION:
The rear wiper may be inoperative or intermittently inoperative. DTC - Rear Wiper Output Short, may be present in the BCM. This DTC is logged when
a short circuit on the Rear Wiper Output circuit is detected. Care must be taken to diagnose proper functionality of circuits for the following conditions:
DIAGNOSIS/REPAIR PROCEDURES:
Use the DRBIII(R) to check for BCM DTC.
Rear Wiper Inoperative No BCM DTC - Disconnect the rear wiper motor connector and check Circuit Number (W13), color (BR/LG), pin 3, (Fig. 1),
for 12 volts when rear wiper switch is activated and ignition switch in Run position. If 12 volts is measured, perform Repair Procedure One, if no voltage
is present, continue with Diagnosis
Rear Wiper Inoperative No BCM DTC and No Voltage At Rear Wiper Connector Pin 3 - Disconnect BCM connector (C2). Verify continuity between
pin 3 of the rear wiper connector and pin 32 of the BCM connector (C2), circuit number (W13), color (BR/LG), (Fig. 1). If no continuity, perform
Repair Procedure Two. If continuity is present, perform Repair Procedure Three.
Rear Wiper Motor Inoperative With BCM DTC - Rear Wiper Output Short (Rear Washer Will Also Be Inoperative) - Check circuit number (W13),
color (BR/LG), pin 3, (Fig. 1) of rear wiper motor connector for a short to ground. If a short is detected, disconnect BCM connector (C2) to verify that
pin 32 is not bent. With BCM connector (C2) disconnected verify, at pin 32 of BCM connector (C2), that the short to ground is still present. If short is
