Cam Belt Routing

4.

Install the timing belt. Recheck all alignment marks.

Fig. 21 Adjusting drive belt tension

5.

Set the belt tension, so that the Chrysler belt tension tool's (#C- 4703) axis is within 15° of horizontal.

6.

Rotate the crankshaft two revolutions in the clockwise direction, then position at TDC. Tighten the tensioner locknut.

7.

Reverse steps #1 through #6 to complete installation.
