Grand Caravan AWD V6-3.8L VIN L (2001)
Service and Repair" See: Instrument Panel, Gauges and Warning Indicators/Instrument Cluster / Carrier/Service and Repair
5. Reconnect the battery negative cable.
A/C Heater Control - Rear
REMOVAL
1. Disconnect and isolate the battery negative cable.
Fig.1 Heater - A/C Control
2. Using a trim stick or another suitable wide flat bladed tool, gently pry the top edge of the rear heater-A/C control bezel away from the headliner far
enough to release the two snap clip retainers.
3. Pull the rear heater-A/C control and bezel unit rearward far enough to access the headliner wire harness connector on the back of the control.
4. Disconnect the headliner wire harness connector for the rear heater-A/C control from the control connector receptacle.
5. Remove the rear heater-A/C control from the headliner.
Fig.2 Heater - A/C Control Bezel
6. Remove the three screws that secure the rear heater-A/C control to the bezel.
7. Remove the rear heater-A/C control from the bezel.
INSTALLATION
1. Position the rear heater-A/C control onto the bezel.
2. Install and tighten the three screws that secure the rear heater-A/C control to the bezel. Tighten the screws to 2 Nm (17 in. lbs.).
