Grand Caravan FWD V6-181 3.0L SOHC (1993)
Trim Panel: All Technical Service Bulletins
Quarter Trim Panel - Cracks
NO.: 23-42-93
GROUP: Body
DATE: Jul. 16, 1993
SUBJECT:
Left Side Upper Quarter Trim Panel Cracks
MODELS:
1991-1993 (AS) Grand Caravan/Grand Voyager/Town & Country
DISCUSSION:
If it becomes necessary to replace the left side upper quarter trim panel due to a crack at or near the middle seat shoulder harness opening, do not install
the screw attaching the trim panel located directly below the middle seat shoulder harness opening. Refer to the illustration.
To prevent the possibility of developing a rattle condition, install a foam or felt pad on the bracket the omitted screw was installed into.
POLICY: Information Only
