Grand Caravan FWD V6-181 3.0L SOHC (1993)
b.
Inspect wheel build date codes located above valve stem (Figure 1).
NOTE:
Date code may be covered by a green sticker. Remove and discard sticker as necessary.
A2.
FOR VEHICLES EQUIPPED WITH 15" FULL SIZE STAMPED STEEL SPARE (Sales Code -- TBB):
a.
Gain access to spare.
b.
Inspect wheel build date code located above valve stem (Figure 1).
NOTE:
Date code may be covered by a green sticker. Remove and discard sticker as necessary.
A3.
If any of the wheels inspected contain a month/day code of 3/31, 4/01, 4/02, 4/05, or 4/06, replace the affected wheel as instructed in Section B. If
none of the wheels have one of the date codes listed, reinstall wheel covers and/or secure spare, no further action is required.
NOTE:
Replace only those wheels having one of the date codes listed above.
B. Replace Wheel
B1.
Remove all wheels with suspect month/day codes above. Discard lug nuts.
B2.
Remove tire(s) from wheel(s). Set wheel(s) aside for return to Warranty Material Return Center.
B3.
Install supplied valve stem(s).
B4.
Mount and balance tire(s) on supplied wheel(s).
B5.
Install wheel and tire assembly on vehicle using supplied lug nuts. Tighten lug nuts to 95 ft-lbs (130 N.m) torque.
B6.
Reinstall wheel cover(s) and/or secure spare.
Stamped Steel Wheel Inspection Instructions
STAMPED STEEL WHEEL INSPECTION INSTRUCTIONS
1993 DODGE CARAVAN AND GRAND CARAVAN; PLYMOUTH VOYAGER AND GRAND VOYAGER; AND CHRYSLER TOWN &
COUNTRY
