Magnum V6-2.7L VIN R (2005)
Radius Arm: Service and Repair
STRUT - TENSION
REMOVAL
1. Raise and support vehicle.
2. Remove wheel mounting nuts (3), then tire and wheel assembly (1).
3. Remove belly pan.
4. Loosen nut (3) attaching tension strut (2) ball joint stud to knuckle. Back nut off until nut is even with end of stud. Keeping nut on at this location
will help keep end of stud from distorting while using Puller in next step.
CAUTION: In following step, use care not to damage ball joint seal boot while sliding Puller, Special Tool 9360, into place past seal boot.
