Nitro 2WD V6-4.0L (2007)
Relay-Trailer Tow-Left
Component ID:
239
Component :
RELAY-TRAILER TOW-LEFT
Connector:
Name :
RELAY-TRAILER TOW-LEFT
Color :
# of pins :
5
Gender :
FEMALE
Pin
Description
Circuit
1
GROUND
Z919 18BK/PK
2
LEFT REAR STOP/TURN SIGNAL CONTROL L63 18DG/WT
3
LEFT REAR STOP/TURN SIGNAL FEED
L673 16YL
4
TRAILER TOW BRAKE LAMP RELAY OUTPUT
L651 16WT/LG
5
TRAILER TOW BRAKE LAMP RELAY OUTPUT
L76 16WT/BR
Component Location - 59
