RAM 3500 Truck 2WD V8-5.9L VIN Z LDC (1999)
Camshaft: Specifications
Bearing Diameter
No.1
2.000 - 2.001 in
No.2
1.984 - 1.985 in
No.3
1.969 - 1.970 in
No.4
1.953 - 1.954 in
No.5
1.5625 - 1.5635 in
Bearing Journal Diameter
No.1
1.998 - 1.999 in
No.2
1.982 - 1.983 in
No.3
1.967 - 1.968 in
No.4
1.951 - 1.952 in
No.5
1.5605 - 1.5615 in
Bearing to Journal Clearance
Standard
0.001 - 0.003 in
Service Limit
0.005 in
Camshaft
End Play
0.002 - 0.010 in
Valve Lift (@ zero lash)-Intake
0.410 in
Valve Lift (@ zero lash)-Exhaust
0.417 in
Valve Timing
Exhaust Valve
Closes (ATDC) 33 deg
Opens (BBDC) 56 deg
Duration
269 deg
Intake Valve
Closes (ATDC) 62 deg
Opens (BBDC) 7 deg
Durataion
249 deg
Valve Overlap
41 deg
Camshaft Bolt
50 ft.lb
Camshaft Thrust Plate Bolts
210 in.lb
