Sprinter 3500 L5-2.7L DSL Turbo (2004)
![background image](/dodge/sprinter_3500/l5-2.7l_dsl_turbo/Page-1800001.png)
Trim Panel: Service and Repair
Front Door Trim Panel
TRIM PANEL
REMOVAL
(1) Disconnect and isolate battery negative cable.
(2) Using a small flat bladed tool or equivalent, press retaining clip upward through cutout in handle cover and remove cover. (Fig. 17)
(3) Remove switch bezel arid disconnect electrical connectors.
(4) Remove the screws. (Fig. 18)
(5) Remove mounting ring and remove window crank, if equipped.
