Pin

Description

Circuit

  1

ACTUATOR MOTOR-WATER VALVE-REAR HEATING

2726 20BR/WT

  2

POTENTIOMETER-WATER VALVE-REAR HEATING

2730 20GY/WT

  3

BLOWER CONTROL SIGNAL-REAR HEATING

2731 20DG/RD

  4

POTENTIOMETER-WATER VALVE-REAR HEATING

2729 20RD/WT

  5

ACTUATOR MOTOR-WATER VALVE-REAR HEATING

2727 20YL/WT

  6

POTENTIOMETER-WATER VALVE-REAR HEATING

2728 20BK/WT

  7

-

-

  8

-

-

Connector:

Name :

CONTROL-A/C-HEATER C7

Color :
# of pins :

8
