Dodge Stratus Sedan V6-2.7L VIN R (2002)03 · Maintenance
03 · Maintenance

Alignment: Specifications (page 6 of 7)

Make
Dodge
Model
Stratus Sedan
Engine
V6-2.7L VIN R
Year
2002
Section
Alignment
MaintenanceSpecifications · page 6 of 7
background image

center of the upper ball joint (or strut) and the lower ball joint. S.A.I. is built into the vehicle and is not an adjustable angle. If S.A.I. is not within
specifications, a bent or damaged suspension component may be the cause.

INCLUDED ANGLE (I. A.)

Included angle is the sum of the S.A.I. angle plus or minus the camber angle, depending on whether or not the wheel has positive or negative camber.
If camber is positive, add the camber angle to the S.A.I. angle. If camber is negative, subtract the camber angle from the S.A.I. angle. Included angle is
not adjustable, but can be used to diagnose a frame misalignment or bent suspension component (spindle, strut).

THRUST ANGLE
