Eagle Wagon L6-258 4.2L (1984)
^
Do not assume that a water leak has only one source. A single water leak may have as many as three sources.
^
Seal each leak source as soon as it is located and respray the same zone. This checks the repair and will reveal any further leak sources in that
zone.
^
Do not apply the water stream directly against window seams or fresh air vents. This may create temporary and false leaks that can hinder
accurate diagnosis.
Analyzing Results of the Water Test
The following charts provide a more detailed analysis of the water test results and possible leak sources located during testing.
Each spray zone is covered individually and possible causes along with recommended repairs and sealers are outlined.
ZONE 1
ZONE 1
Test Results:
^
Water under front/rear carpet or in luggage compartment
Possible Causes:
^
Loose-missing fasteners (carpet, brake lines, seat belt bolts)
^
Loose floorpan grommets or tank unit inspection cover
^
Loose torsion bar fastener
^
Gaps in floor panel joints
Repair:
^
Tighten and seal with 3M08575
^
Spray underbody sealer 8983 100 004 on faulty panel joints
ZONE 2
ZONE 2
Test results:
^
Water on floor near:
^
Apillars
^
B-C pillars or in luggage compartment
Possible Causes:
^
Faulty sealing or sealer out of position on panel joints
^
Faulty sealing of shock absorber tunnels
^
Loose seat belt bolts
^
Loose shock absorber fasteners
Repair
^
Apply 3M08646 seam sealer on faulty panel joints or use a sprayable type sealer such as Kent Ind. BFG-80405
^
Tighten fasteners (seat belt bolts, shock absorbers, etc.)
