Ignition Relay: Locations
- Make
- Eagle
- Model
- Premier
- Engine
- L4-150 2.5L
- Year
- 1988
- Section
- Ignition System › Ignition Relay › Locations
Powertrain ManagementLocations · page 1 of 2
Ignition Relay: Locations
Ignition Control Module
The Ignition Relay is mounted in the engine compartment on the left strut tower under a labeled cover with several other relays.
