Contour V6-153 2.5L DOHC (1996)
30.
Install three-way catalytic converter to Y-pipe retaining nuts. Tighten nuts to 30-40 Nm (22-30 lb/ft).
31.
Install three-way catalytic converter to muffler inlet retaining nuts. Tighten nuts to 34-46 Nm (26-33 lb/ft).
32.
Lower vehicle.
33.
From engine compartment, perform the following:
^
Connect right (rear) oxygen sensor electrical connector.
^
Tighten EGR tube to EGR valve to 35-45 Nm (26-33 lb/ft).
^
Connector idle air control vacuum hose.
^
Connect idle air control electrical connector.
34.
Connect battery negative cable.
35.
Remove memory saver.
36.
Start vehicle and check for exhaust leaks.
AUTHORIZED MODIFICATION LABEL
^
Prepare and attach the preprinted Authorized Modifications Label provided in the kit of parts. Write you P & A Code and date of repair as shown.
REMOVAL CATALYSTS
Removed catalysts must be returned. An FPS-700 Parts Disposition Tag will be issued to recall the removed catalysts. Return of removed catalysts with
the FPS-700 tag attached must be shipped prepaid freight via United Parcel Service (UPS) to the address on the reverse side of the tag.
Refer to the part return shipping procedure in Section 7.0 of the Warranty and Policy manual.
ANY QUESTIONS ON THE HANDLING OF SPECIAL SITUATIONS REGARDING REMOVED CATALYSTS SHOULD BE RESOLVED WITH
YOUR SERVICE ZONE MANAGER.
Service Part Number: Kit B
AFFECTED VEHICLES
CERTAIN 1995 AND 1996 CONTOUR AND MYSTIQUE CARS, EQUIPPED WITH 2.5L ENGINE AND BUILT AT THE KANSAS CITY
ASSEMBLY PLANT FROM START OF 1995 PRODUCTION THROUGH MARCH 10, 1996, AND CUAUTITLAN ASSEMBLY PLANT FROM
