Intake Manifold Runner Control Actuator: Service and Repair

ELECTRIC ACTUATOR AND CABLE ASSEMBLY

1. Perform the fuel pressure release procedure.  See: Fuel Filter/Fuel Pressure Release/Service and Repair
2. Disconnect battery ground cable.
3. Remove upper intake manifold.
4. Remove screws retaining water pump pulley shield to LH valve cover. Disconnect vent hose and remove water pump pulley shield.

Actuator Cable

5. Disconnect actuator cable from runner control lever, cable bracket, water bypass stud and cable bridge.
6. Disconnect harness connector from electric actuator and cable assembly.
