4. Repeat the above three steps to complete the removal of the twist at the lower (wider and larger) slot in the tongue.

5. When completed, safety belt tongue should face outward.

Safety Belt Twisted at Safety Belt Guide

PROCEDURE

1. Grasp belt webbing at the front safety belt guide.
2. Rotate and fold belt webbing over itself as required to remove the twist.
3. Feed the fold portion of the belt through the front safety belt guide.
