Contour V6-153 2.5L DOHC VIN L SFI (1997)
7. Install the reverse clutch hub retaining ring.
8. Turn the assembly over and install the forward/coast/direct clutch cylinder hub seal on the forward/coast/direct clutch cylinder.
Coast Clutch Piston Seal Sizing
9. Use Coast Clutch Piston Seal Sizer T94P-77000-D4 (part of Clutch Piston Seal Protector/Sizer Set T94P-77000-D) to size the
forward/coast/direct clutch cylinder hub seal. Leave the seal sizer on until the forward/coast/direct clutch cylinder is installed in the transaxle case.
Low/Reverse Clutch Piston
