Contour V6-153 2.5L DOHC VIN L SFI (1997)
^
bushing
^
check balls in pistons
^
piston bore
^
passages and lube holes in the F/C/D clutch cylinder
Assembly
1. Soak the internal spline clutch plates in clean transmission fluid for 15 minutes before assembly.
2. Install the forward clutch piston inner seal in the forward/coast/direct clutch cylinder assembly.
Forward Clutch Piston Outer Lip Seal Installation
3. Install the forward clutch piston outer lip seal on the forward clutch piston assembly.
4. Install the forward clutch piston assembly in the forward/coast/direct clutch cylinder assembly.
5. Install the coast clutch piston assembly in Coast Clutch Piston Seal Protector T94P-77000-D3 (part of Clutch Piston Seal Protector/Sizer Set
