Crown Victoria V8-4.6L SOHC VIN W (2005)
Mark the position of the inboard track C-channel to the plastic-coated slide as shown.
Passenger seats
10. Remove the heated seat module bracket nut and position aside the heated seat module bracket.
All seats
11. Remove the two nuts at the lift links.
12. NOTE:
-
The drive tube is press-fit to stub shafts on each end. A hammer may be necessary to separate the drive tube.
-
The drive tube must be clamped at the inboard track gear stub shaft to allow the drive tube to separate at the seat track motor gear stub shaft.
Clamp the locking pliers on the flats of the drive tube where it reaches over the inboard track gear stub shaft. Tap on the locking pliers, separate
the drive tube from the seat track motor assembly stub shaft and remove the inboard track and drive tube.
